Ubiquiti UniFi 24-Port Gen2 Managed Gigabit Switch with SFP

MPN: USW-24

SKU: UBI-USW-24

$229


  • (24) Gigabit Ethernet Ports

  • (2) Gigabit SFP Ports

  • 1.3" color touchscreen for status information

  • Managed with UniFi Network application

  • 1U rackmountable (kit included)

Availability Available 2 in stock.
Ask about this product
Delivery and Return
Description

UniFi Switch 24

UniFi Switch 24 is a fully managed Layer 2 switch with (24) Gigabit Ethernet ports and (2) Gigabit SFP ports for fiber connectivity

The USW-24 is a configurable Layer 2 switch with 24 Gigabit Ethernet ports and 2 SFP ports. The SFP ports provide 1 Gbps fiber uplink options to your enterprise network. The USW-24 features a 1.3" touchscreen, compact size, and fanless design. The touchscreen displays the current switch state and information for quick diagnosis. Managed and configured by the UniFi Network application with UniFi mobile app support, the USW-24 switch offers an extensive suite of advanced Layer 2 switching protocols and features, including operating mode (switching, mirroring, or aggregate) per port.

Features:

  • (24) Gigabit Ethernet Ports
  • (2) Gigabit SFP Ports
  • 1.3" color touchscreen for status information
  • Managed with UniFi Network application
  • 1U rackmountable (kit included)

Managed with UniFi Network Application Version: 5.12.32 or higher
Dimensions

442.4 x 200 x 43.7 mm (17.42 x 7.87 x 1.72")
Weight

Without Mount: 2.70 kg (5.95 lb)

With Mount: 2.79 kg (6.15 lb)
Enclosure Material

SGCC Steel
Total Non-Blocking Throughput

26 Gbps
Switching Capacity

52 Gbps
Forwarding Rate

38.69 Mpps
Max. Power Consumption

25W
Power Method

Universal AC Input: 100-240VAC, 50/60 Hz
Power Supply

AC/DC, Internal, 36W
Networking Interfaces

(24) 10/100/1000 Mbps Ethernet RJ45 Ports

(2) 1 Gbps SFP Ports
Management Interface

Ethernet In-Band
Modes

SMB Layer 2 Gigabit Ethernet Switch
ESD/EMP Protection

Air: ± 16 kV, Contact: ± 12 kV
Operating Temperature

-5 to 40° C (23 to 104° F)
Operating Humidity

10 - 90% Noncondensing
Certifications

CE, FCC, IC
