MikroTik Lite5 RouterBOARD 600MHz CPU 64MB 5GHz Single Chain

Mikrotik

MikroTik Lite5 RouterBOARD 600MHz CPU 64MB 5GHz Single Chain

MPN: RB911-5HN

SKU: MIK-RB911-5HN

$36
$39
Availability Available 4 in stock.
Ask about this product
Delivery and Return
Description

MikroTik 911 Lite5 – Perfect for building low cost CPE devices


The RB911-5Hn is a small CPE type RouterBOARD wireless router with an integrated 5GHz single chain wireless card. It’s equipped with powerful 600MHz CPU, providing superb value for money.


The integrated wireless card is capable of up to 1000mW output power. It has built in 16kV ESD protection on both the Ethernet and the MMCX ports.













































































































































Product specifications
Product code RB911-5Hn
CPU nominal frequency 600 MHz
CPU core count 1
Size of RAM 64 MB
Architecture MIPS-BE
10/100 Ethernet ports 1
10/100/1000 Ethernet ports None
MiniPCI slots 0
MiniPCI-e slots 0
Wireless chip model AR9344-DC3A-R
Wireless standards 802.11a/n
Number of USB ports 0
Power Jack 0
802.3af support No
Supported input voltage 8 V - 30 V
PoE in Yes
PoE out No
Voltage Monitor No
PCB temperature monitor No
CPU temperature monitor No
Dimensions 105x105mm
Operating System RouterOS
License level 3
Tested ambient temperature -40°C ~ +70°C tested
Current Monitor No
CPU AR9344-DC3A-R
Max Power consumption 5 W
SFP ports 0
SFP+ ports 0
Number of chains 1
Serial port None
Storage type FLASH
Storage size 16 MB

Wireless specifications






































5 GHz
  Transmit power (dBm) Receive Sensitivity Transmit power (mW)
6MBit/s 23 -93 200
54MBit/s 19 -74 79
MCS0 23 -93 200
MCS7 18 -68 63

wireless parameters may be limited in software, depending on your local regulatory limitations


Ethernet test results










































































RB911-5Hn AR9344 100M 1 port test
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 8.1 98.4 23.5 96.3 148.0 75.8
Bridging 25 bridge filter rules 8.1 98.4 23.5 96.3 87.6 44.9
Routing none (fast path) 8.1 98.4 23.5 96.3 148.0 75.8
Routing 25 simple queues 8.1 98.4 23.5 96.3 106.6 54.6
Routing 25 ip filter rules 8.1 98.4 23.5 96.3 60.5 31.0


  • All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)

  • Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes

  • Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out

  • Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
