Tycon RemotePro 20W Power System 80W Solar Panel 12V 104Ah Battery (48V PoE)

Tycon Solar RPST1248-100-80 is a RemotePro power system designed for use in powering wireless base stations, surveillance cameras, and more with 20W of continuous power.

The RPST1248-100-80 RemotePro series outdoor power system is designed for applications that require a primary off-grid power source to run various equipment. The vented weatherproof enclosures have generous space available inside for mounting customer equipment. The high quality solar panels have a 25 year power output guarantee, and comes with a side of pole mounting bracket for mounting to a pole or wall. The battery is 12V with a 48V PoE output (up to 30W), with 100Ah of capacity and up to 20W of continuous power generation, with an 80W solar panel.

Product Features
• Complete Remote Power Solution for Off-Grid Operation
• Weatherproof Outdoor Enclosure with a 100Ah Battery
• Enclosures can be Wall or Pole Mounted
• High Performance Sealed Lead Acid Batteries
• PWM Charge Controllers
• Thermostatically Controlled Ventilation

Product Applications
• Wireless Base Stations
• Surveillance Cameras
• Wireless Bridge and Repeaters
• Off Grid Power
• Remote Lighting
• Backup Power Systems

Product Specifications
• Rated Power Generation: 20W
• Reserve Time @ Rated Power: 30hrs
• PoE Output Voltage (DC) 30W: 48V
• Load Out (DC): 11-15V, 1.5A
• 12V Battery Capacity (Amp Hrs): 100Ah
• Battery Voltage (DC): 12V
• Battery Type: Maintenance Free Non-Spillable Valve Regulated Sealed Lead Acid AGM
• Battery Life: 5+ years
• Solar Controller Type: PWM (Pulse Width Modulated)
• Overcharge Protection: 14.4V
• Over-Discharge Protection: 11.0V
• Over-Discharge Recovery Volts: 12.0V
• Controller Self Consumption: <0.5W
• Enclosure Type: Pole/Wall Mount, Powder Coat Steel
• Enclosure External Size: 24 x 15 x 14" (610 x 381 x 356mm)
• Enclosure Internal Size: 23 x 14 x 12" (584 x 346 x 305mm)
• Internal Mount Features: Din Rail Mounts (3)
• Solar Panel Dimensions: 34 x 26" (855 x 666mm)
• Operating Temperature: -30 to 60°C (-22 to 140°F)
• System Weight (no batteries): 86lbs (39kg)
• Battery Weight: 81lbs (37kg)
• Wind Speed Rating: 90mph
• Warranty: 2 Years
• Continuous Power Generation: 20W
• Backup Time: >30hrs
• Battery Voltage: 12VDC
• PoE Output Voltage: 48V
• 12V Battery Capacity: 100Ah
• Solar Panel Size: 80W
