PLANET GST-705A 1000Base-T to Mini-GBIC Smart Gigabit Converter

PLANET TECHNOLOGY GST-705A 1000Base-T to Mini-GBIC Smart Gigabit Converter NEW

• Complies with IEEE 802.3ab, 1000Base-T and IEEE 802.3z 1000Base-LX/ SX Ethernet standard


• Provides one 1000Base-T port with RJ-45 connector and one 1000Base-LX/ SX port for LC/ SFP connector for supporting multi-mode or single-mode fiber optic cable


• LED indicators for converter status


• Provides DIP switch to set fiber (Auto-negotiation/ Manual) and LLR (Disable/ Enable)


• Auto-MDI/ MDI-X for 1000Base-T port


• Back-pressure, IEEE 802.3x compliant flow control and full wire speed forwarding rate


• Link Loss Return (LLR) switch on each fiber optic to aid in troubleshooting remote network connections


• Link Loss Carry Forward (LLCF) works with LLR in diagnosing network connections


• Manageable through Web Smart Media Converter Chassis System


• Uses as a stand-alone device or with a chassis for up to 16 converter with redundant power supply for optional expanding use


• EMI standards comply with FCC, CE class B
