Mikrotik
MPN: CRS125-24G-1S-2HnD-IN
SKU: MIK-CRS12524G1S2HND
Cloud Router Switch is our new Smart Switch series. It is a fully functional Layer 3 switch, and is powered by the familiar RouterOS. All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes.
What’s more - this device has a built in 2.4GHz wireless access point, this means you can have an AP, a router with any number of ports, and a full wire speed smart switch, all in one device - ideal for medium/small businesses and offices. It has 24 Gigabit ports, one SFP cage, a microUSB port and a built in Wireless AP.
The perfect SOHO gateway router, switch & 11n AP all in one box.
Details |
|
| Product code | CRS125-24G-1S-2HnD-IN |
| SFP DDMI | Yes |
| CPU nominal frequency | 600MHz |
| CPU core count | 1 |
| Architecture | MIPS-BE |
| Size of RAM | 128MB |
| 10/100 Ethernet ports | 0 |
| 10/100/1000 Ethernet ports | 24 |
| MiniPCI slots | 0 |
| Wireless standards | 802.11b/g/n |
| Number of USB ports | 1 |
| Power Jack | 8-28V DC |
| Voltage Monitor | yes |
| PCB temperature monitor | yes |
| CPU temperature monitor | yes |
| Dimensions | 285x145x45mm |
| Operating System | RouterOS |
| Temperature range | -35°C to +65°C |
| License level | L5 |
| Antenna gain | 4dBi |
| TX power | 30dBm |
| CPU | Qualcomm Atheros AR9344 |
| SFP ports | 1 |
| USB slot type | microUSB type AB |
| Number of chains | 2 |
| Serial port | RJ45 |
| Storage type | NAND |
| Storage size | 128MB |
| 2.4 GHz | |||
| Transmit power (dBm) | Receive Sensitivity | Transmit power (mW) | |
| 1MBit/s | 29 | -97 | 794 |
| 11MBit/s | 28 | -90 | 631 |
| 6MBit/s | 30 | -96 | 1000 |
| 54MBit/s | 25 | -76 | 316 |
| MCS0 | 30 | -96 | 1000 |
| MCS7 | 23 | -73 | 200 |
wireless parameters may be limited in software, depending on your local regulatory limitations
| CRS125-24G-1S-2HnD-IN | |||||||
| Mode | Configuration | 64 byte | 512 byte | 1518 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Switching | Non blocking Layer 2 throughput | 37,202.4 | 19,047.6 | 5,874.1 | 24,060.2 | 2,031.9 | 24,674.9 |
| Switching | Non blocking Layer 2 capacity | 37,202.4 | 38,095.2 | 5,874.1 | 48,120.3 | 2,031.9 | 49,349.8 |
| Switching | Non blocking Layer 1 throughput | 37,202.4 | 25,000.0 | 5,874.1 | 25,000.0 | 2,031.9 | 25,000.0 |
| Switching | Non blocking Layer 1 capacity | 37,202.4 | 50,000.0 | 5,874.1 | 50,000.0 | 2,031.9 | 50,000.0 |
| CRS125-24G-1S-2HnD-IN | AR9344 1G all port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 81.0 | 983.7 | 232.0 | 950.3 | 269.6 | 138.0 |
| Bridging | 25 bridge filter rules | 81.0 | 983.7 | 86.0 | 352.3 | 87.6 | 44.9 |
| Routing | none (fast path) | 81.0 | 983.7 | 210.0 | 860.2 | 226.9 | 116.2 |
| Routing | 25 simple queues | 81.0 | 983.7 | 103.9 | 425.6 | 106.6 | 54.6 |
| Routing | 25 ip filter rules | 56.8 | 689.8 | 59.6 | 244.1 | 60.5 | 31.0 |
