Ubiquiti UDM-SE Dream Machine Special Edition
Ubiquiti UDM-SE Dream Machine Special Edition
Ubiquiti UDM-SE Dream Machine Special Edition
Ubiquiti UDM-SE Dream Machine Special Edition
Ubiquiti UDM-SE Dream Machine Special Edition
Ubiquiti UDM-SE Dream Machine Special Edition

Ubiquiti Networks

Ubiquiti UDM-SE Dream Machine Special Edition

MPN: UBI-UDM-SE

SKU: UBI-UDM-SE

$509


  • Integrated 8-port PoE Switch

  • 128 GB of integrated storage

  • LAN ports: (8) GbE RJ45, (1) 10G SFP+

  • WAN ports: (1) 2.5GbE RJ45, (1) 10G SFP+

  • Threat management and traffic/client identification

  • (1) 3.5" HDD bay for storing UniFi Protect recordings

Availability Available 1 in stock.
Ask about this product
Delivery and Return
Description

Dream Machine Special Edition

All-in-one, enterprise-grade UniFi OS Console and security gateway designed to host the full UniFi application suite.

Enables control of networking, cameras, phones, and door access, while serving as a gateway for your network.

Features:

  • Integrated 8-port PoE Switch
  • 128 GB of integrated storage
  • LAN ports: (8) GbE RJ45, (1) 10G SFP+
  • WAN ports: (1) 2.5GbE RJ45, (1) 10G SFP+
  • Threat management and traffic/client identification
  • (1) 3.5" HDD bay for storing UniFi Protect recordings
Mechanical
Dimensions

442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24")
Weight

4.95 kg (10.91 lb)
Enclosure materials

Aluminium CNC, SGCC steel
Mount material

SGCC steel rack mount
Hardware
Processor

Quad-Core ARM® Cortex®-A57 at 1.7 GHz
System memory

4 GB DDR4
On-board storage

16 GB eMMC
Integrated 128 GB SSD
IDS/IPS throughput

3.5 Gbps*

*Measured with iPerf3
Max. power consumption (excluding PoE output)

50W
Power method

(1) Universal AC input, 100-240VAC, 4.4A Max, 50/60 Hz

(1) USP-RPS DC input, 52VDC, 3.94A
Power supply

AC/DC, Internal, 240W
Supported voltage range

100 to 240VAC
Management interfaces

Ethernet
Bluetooth
Networking interfaces

(1) WAN: 2.5 GbE RJ45 port
(8) LAN: 1 GbE RJ45 ports
SFP+ interfaces

(1) WAN: 10G SFP+

(1) LAN: 10G SFP+
PoE interfaces

(2) PoE+ (pair A 1, 2+; 3, 6-)

(6) PoE (pair A 1, 2+; 3, 6-)
Max. PoE wattage per port by PSE PoE

15.4W
Max. PoE wattage per port by PSE PoE+

30W
Voltage range PoE mode

44 to 57V
Voltage range PoE+ mode

50 to 57V
ESD/EMP protection

Air: ± 15 kV, contact: ± 8 kV
LCM display

(1) 1.3" touchscreen

Bootup animation: bootup in progress

Firmware upgrade icon: firmware upgrading
Button

Factory reset
Operating temperature

-10 to 40° C (14 to 104° F)
Operating humidity

5 - 95% noncondensing
Certifications

CE, FCC, IC
LEDs
Ethernet

White: link/activity
SFP+

White: link/activity
HDD

White: disk activity

Amber: disk error
RPS

Blue: ready
