MikroTik hAP ac3 5 GbE Port Dual-Band 2.4/ 5 GHz Home Access Point
MikroTik hAP ac3 5 GbE Port Dual-Band 2.4/ 5 GHz Home Access Point
MikroTik hAP ac3 5 GbE Port Dual-Band 2.4/ 5 GHz Home Access Point
MikroTik hAP ac3 5 GbE Port Dual-Band 2.4/ 5 GHz Home Access Point
MikroTik hAP ac3 5 GbE Port Dual-Band 2.4/ 5 GHz Home Access Point

Mikrotik

MikroTik hAP ac3 5 GbE Port Dual-Band 2.4/ 5 GHz Home Access Point

MPN: RBD53iG-5HacD2HnD-US

SKU: MIK-RBD53IG5HACD2HND

$109


  • 5x Gigabit Ethernet ports

  • PoE-in/PoE-out

  • Powerful external high gain antennas (3 – 5.5 dBi)

  • 2.4 GHz 802.11 b/g/n dual-chain, 5 GHz 802.11 a/n/ac dual-chain

  • Strong dual-chain dualband 2.4/5 GHz Wireless

Availability Available 4 in stock.
Ask about this product
Delivery and Return
Description
hAP ac³A wireless dual-band router with 5 Gigabit Ethernet ports and external high gain antennas for more coverage

Forget about endless searching for the perfect router and scrolling through an eternity of reviews and specifications! We have created a single affordable home access point that has all the features you might need for years to come.

Is your old router struggling to reach every corner of your home? Well, forget about that! We have included external high gain wireless antennas with outstanding coverage. Only strong and stable wireless connection in every room from now on!

With 5 Gigabit Ethernet ports, 256 MB of RAM and quad-core CPU, hAP ac³ can satisfy even the biggest and most demanding households. With PoE support, it can power or be powered by other devices. There is a 128 MB NAND and a full-size USB port that you can use to add extra storage. The new enclosure allows mounting the device vertically or horizontally. A wall mount set is also included.



Specifications

Details
Product code RBD53iG-5HacD2HnD
Architecture ARM 32bit
CPU IPQ-4019
CPU core count 4
CPU nominal frequency 716 MHz
Dimensions 251 x 129 x 39 mm
RouterOS license 4
Operating System RouterOS
Size of RAM 256 MB
Storage size 128 MB
Storage type NAND
Tested ambient temperature -40°C to 70°C
MTBF Approximately 100'000 hours at 25C
Suggested price $99.00


Wireless capabilities

Details
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Antenna gain dBi for 2.4 GHz 3
Wireless 2.4 GHz chip model IPQ-4019
Wireless 2.4 GHz generation Wi-Fi 4
Wireless 5 GHz Max data rate 867 Mbit/s
Wireless 5 GHz number of chains 2
Wireless 5 GHz standards 802.11a/n/ac
Antenna gain dBi for 5 GHz 5.5
Wireless 5 GHz chip model IPQ-4019
Wireless 5 GHz generation Wi-Fi 5
AC speed AC1200


Ethernet

Details
10/100/1000 Ethernet ports 5
Number of 1G Ethernet ports with PoE-out 1


Peripherals

Details
Number of USB ports 1
USB Power Reset Yes
USB slot type USB type A
Max USB current (A) 1


Powering

Details
PoE in Passive PoE
PoE in input Voltage 18-28 V
Number of DC inputs 2 (DC jack, PoE-IN)
DC jack input Voltage 12-28 V
Max power consumption 30 W
Max power consumption without attachments 12 W
FAN count Passive


PoE-out

Details
PoE-out ports Ether5
PoE out Passive PoE
Max out per port output (input < 30 V) 0.5 A
Max total out (A) 0.5 A


Certification & Approvals

Details
Certification CE, FCC, IC, EAC, ROHS


Other

Details
Mode button Yes


Wireless specifications

2.4 GHz Transmit (dBm) Receive Sensitivity
1MBit/s 25 -100
11MBit/s 25 -94
6MBit/s 26 -96
54MBit/s 23 -78
MCS0 26 -96
MCS7 22 -73

5 GHz Transmit (dBm) Receive Sensitivity
6MBit/s 26 -96
54MBit/s 22 -80
MCS0 26 -96
MCS7 21 -75
MCS9 19 -70
