Planet Industrial L2+ 16-Port 1G 802.3at PoE + 4-Port 10G SFP+ Managed Ethernet Switch

High-Performance L2+ PoE+ Solution with Static Routing

The IGS-4215-16P4X is PLANET's Industrial-grade, DIN-rail L2+ Managed Gigabit PoE+ Switch, upgraded with L2+ static routing to enhance inter-VLAN communication and network efficiency. It offers 16 10/100/1000BASE-T ports with 802.3at PoE+ (up to 36W per port) and 4 10GBASE-X SFP+ fiber slots for high-speed uplinks.

With a total PoE power budget of 360 watts (achievable only with dual power inputs), it supports diverse PoE applications, including IP cameras and wireless access points. Operating in extreme temperatures from -40 to 75°C, the IGS-4215-16P4X features advanced PoE management, IPv6/IPv4 dual stack support, and a rugged IP30 aluminum enclosure. Its USB Type-C console port ensures simple management, making it a reliable choice for demanding industrial environments.

Cybersecurity Network Solution to Minimize Security Risks

The IGS-4215-16P4X supports SSHv2 and TLSv1.3 protocols to provide strong protection against advanced threats. It includes a range of cybersecurity features such as DHCP Snooping, IP Source Guard, Dynamic ARP Inspection Protection, RADIUS and TACACS+ user accounts management, SNMPv3 authentication, and so on to complement it as an all-security solution.

Modbus TCP Provides Flexible Network Connectivity for Factory Automation

The IGS-4215-16P4X supports the Modbus TCP protocol, allowing for easy integration with SCADA systems, HMI systems, and other data acquisition systems in factory floors. This enables administrators to remotely monitor the industrial Ethernet switch's operating information, port information, communication status, and DI/DO status, thereby enhancing monitoring and maintenance of the entire factory.

Redundant Ring, Fast Recovery for Critical Network Applications

The IGS-4215-16P4X supports redundant ring technology and features strong, rapid self-recovery capability to prevent interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology and Spanning Tree Protocol (802.1s MSTP) into customer’s network to enhance system reliability and uptime in various environments.

Reliable Power and High-speed Data with IEEE 802.3at PoE+ Support

The IGS-4215-16P4X is designed to meet the needs of networks with smaller to medium PoE power demands, complying with the IEEE 802.3at PoE+ standard. It delivers a total power capacity of 360 watts across its 16 PoE+ ports, with each port supporting up to 36 watts of power. This makes it ideal for powering a range of medium-power PoE-compliant devices (PDs) over standard Cat5e/6 Ethernet cabling.

The IGS-4215-16P4X is better suited for applications with multiple devices that require moderate power. It’s an excellent choice for:

• PoE IP cameras
• Wireless access points (APs)
• IP phones and VoIP systems
• Digital signage displays
• Industrial IoT devices

ONVIF Support Allows Effective and Centralized Control Over IP-based Security Products

The IGS-4215-16P4X switch offers ONVIF support as part of its versatile feature set for seamless integration with IP surveillance cameras. Through the switch's web GUI, users can easily search for and display all ONVIF-compliant devices on their LAN.

Users can also upload floor plans to the switch and place IP surveillance cameras on the plan for more intuitive planning and faster inspection in the future. Additionally, the web GUI provides real-time surveillance information, online/offline status, and the ability to remotely reboot cameras.
